Looking to bring in fresh air even when it rains? Want to add a modern, functional touch to your home? That’s exactly what awning windows offer. These top-hinged windows swing outward and provide excellent ventilation, weather protection, and aesthetic value—all in one sleek frame.
Learning how to install an awning window can save you hundreds in professional fees and give you the satisfaction of a job well done. Whether you're upgrading a kitchen, enhancing a bathroom, or simply replacing an old window, this guide walks you through every step—from choosing the right tools to final touches.
In this post, we’ll break down everything you need to know: types of awning windows, pre-install prep, step-by-step installation, and post-install tips. No confusing jargon—just clear, helpful instructions. Let’s get started and make your next home improvement project a breeze.
Awning windows offer something unique. Unlike casement windows that open sideways or sliding windows that move horizontally, awning windows hinge at the top and open outward. That means you can crack them open for fresh air—even during light rain. Here’s a quick comparison:
Feature | Awning Window | Casement Window | Sliding Window |
Hinge Position | Top | Side | None (slides) |
Rain Protection | Excellent | Poor | Poor |
Ventilation Control | High | Moderate | Low |
Ideal for Small Spaces | ✅ | ❌ | ✅ |
Where do these windows shine? Let's break it down:
Kitchens: Placed above sinks, they vent out cooking smells quickly.
Bathrooms: Great for steam removal without giving up privacy.
Bedrooms: Keep air circulating overnight, even if it rains.
Basements & High Sills: Compact frames fit tight spots easily.
Because the sash presses tightly against the frame when shut, awning windows seal well. That tight seal reduces air leaks. When left slightly open, they let in fresh air without compromising insulation. Many come with low-e glass or multi-point locks to boost thermal performance. You’ll feel the difference on your energy bill.
Drill (with 3mm and masonry bits)
Tape measure
Level or spirit level
Screwdriver (Phillips head)
Utility knife
Shims or packers
Staple gun (for flashing, if needed)
Stainless steel or corrosion-resistant screws
Flashing tape or waterproof plastic flashing
Expanding foam (low-expansion only!)
Backer rod and exterior sealant
Interior air-seal caulk
Gloves (cut-resistant)
Safety glasses
A sturdy ladder
A buddy to help lift heavy windows
Before you start, check your local building regulations. Some areas require permits. Others have egress rules (especially for bedrooms). If you’re in a HOA community, you might need approval for exterior changes.
Install windows with at least 20 mm of width and 30 mm of height clearance beyond your unit dimensions. This allows enough space for leveling and insulation. If using a narrow-frame retrofit, double-check measurements before ordering.
Always stabilize your ladder. Avoid overreaching. Have someone hold it. For large windows, two people are safer than one. If your unit weighs over 40 lbs, consider hiring help.
Use a tape measure to get the opening’s height, width, and depth. Measure top, middle, and bottom. Take the smallest numbers.
20 mm wider than the frame
30 mm taller than the unit height
This helps with fitting, leveling, and sealing.
Push-out awning windows: Open manually; minimal hardware
Crank-out awning windows: Open with a handle; easier in tight spots
Motorized models: Ideal for high windows or smart homes
Pick one based on placement and accessibility.
If you're replacing an old unit, a narrow-frame design can slot into the existing hole without major wall work.
Cut the caulk, unscrew fasteners, and carefully remove the window. Clean the area of debris, nails, and old sealants.
Check the studs, sill, and header. Any soft spots? Rot? Replace or repair them before proceeding.
Install or update sill flashing to direct water out. Staple flashing to the back of the frame and fold it under for a watertight base.
Hold the window in place to check spacing. Use a pencil to mark alignment lines.
Hold brackets or clips in place. Mark drill holes. Remove the window.
Line the top and sides of the opening with flashing tape. Overlap corners. Press it down firmly.
From outside, insert the unit into the opening. Have a helper inside guide and support.
Push the frame inward so the reveal extends about 10 mm into the interior wall. This accounts for drywall/plaster thickness.
Place temporary shims under the bottom corners. This holds the window level before fastening.
Measure corner-to-corner. The numbers should match (or be within 2–3 mm). If not, your window’s out of square.
Insert shims along jambs and sill until the frame is plumb. Use a level to confirm.
Ensure consistent spacing between the frame and the wall all the way around.
Drill pilot holes at pre-marked spots. Drive in #10 screws. Don’t overtighten.
Use masonry anchors or expansion bolts. Add backer rod for extra hold.
Start holes in reverse to prevent cracking, then drill forward with care.
Spray low-expansion foam between the window and framing. Avoid overfilling.
Press backer rod into gaps. Apply flexible sealant on top. Smooth with a gloved finger.
Seal the inside with air-tight caulk. Consider vapor barriers for humid rooms.
Attach latches, cranks, or motor kits per manufacturer instructions.
Slide arms into guide tracks. Lock them in. Crank to test smooth movement.
Close the sash. It should contact the frame evenly, creating a tight seal.
Brick veneer: Use longer fasteners; install flashing behind the veneer.
Stucco: Drill through painter’s tape to reduce chipping and dust.
Motorized models: Confirm wiring route before drywall is closed.
Stacked combos: Use coupling kits when placing awnings above picture windows.
Add drywall returns or trim casing inside
Outside, apply aluminum cladding or brick-moulds
Caulk and paint edges or stain wood finishes for durability
Misaligned brackets = stuck or twisted sash
Over-tightened screws = stripped vinyl
Skipped flashing = leaks, mold, regret
Monthly: Open/close to test hardware
Seasonal: Clean tracks, oil hinges
Every 2–3 years: Re-caulk seams and check flashing
Fabric awnings above? Replace every 5–10 years depending on sun exposure
Item | DIY Cost (USD) | Pro Install (USD) |
Standard Window Unit | $200–$600 | — |
Tools & Supplies | $50–$150 | — |
Labor | Free | $150–$500 |
Total | ~$250–$750 | ~$500–$1100 |
Won’t close flush → Shim the frame; adjust sash alignment
Air or water leaks → Re-caulk; check seal compression
Handle slips → Tighten or replace operator hardware
Installing an awning window means better airflow and rain protection.
Start by measuring the rough opening—width, height, and depth.
Pick your window type: crank-out, push-out, or motorized.
Use tools like a drill, level, tape measure, and safety gear.
Prep the opening. Remove old windows. Inspect the frame and add flashing.
Set the new window in place using shims. Make sure it's level and square.
Secure with screws or anchors, depending on wall type.
Seal gaps using foam, caulk, and flashing for a tight fit.
Add hardware. Test that the window opens and closes smoothly.
